Connect up to six additional scales/encoders/MPGs (mix and match) to a Centroid Hickory based CNC control system with the Hickory Encoder expansion board.
The Hickory Encoder Expansion board communicates to the Hickory via FieldBus over Ethernet Communication. Simply install the expansion card in the Hickory Ethernet daisy chain using a shielded Ethernet cable via the RJ45 IN and OUT connectors and CNC12 will automatically recognize the additional encoder ports. Any of the expansion card ports can be used for scale, encoder, or MPG duty and any port can be assigned to any axis of the CNC Controller.
| Encoder Type | Rotary Encoder | Linear Scale | MPG Handwheels |
|---|---|---|---|
| A/B differential quadrature (W/ Index Pulses) |
Yes | Yes | No |
| A/B differential quadrature (W/O Index Pulses) |
No | No | Yes |
| BiSS B/BiSS C Serial Encoders | Yes | Yes | No |
Compatible with:
